AXL ZENSTOR Storage A5U84
A high-density 2U enterprise server platform powered by dual AMD EPYC processors, delivering exceptional compute performance, PCIe Gen5 scalability, and storage flexibility for modern data center workloads.
- Deliver peace of mind with features to protect data, including dual power supplies, fan modules, and I/O modules, as well as dual data paths to all drives
- Easily manage cables, universal ports, self-configuration controls, and standardised zoning
- Seamlessly expand to 336 drives as business grows
- Efficiently manage your data centre with a 5U rackmount enclosure and unique drawer design that provides easy access to drives
- Maximum of 28.8 GB/s in a dual controller configuration
Enterprise performance, engineered in India
Zenstor A5U84 is the datasphere’s ideal platform for Storage expansion, supporting efficient growth, high capacity high performance platform that can delivers ultimate scalability. Build exabyte-scale storage infrastructure.
Where it excels
Virtualization & private cloud · databases & applications · consolidation and edge deployments · enterprise data-center environments.
| Specifications | ||
| Controller | Dual EBOD storage bridge bay (SBB) 2.1 compatible I/O modules per enclosure | |
| Host/Expansion Interface | Three universal x4 12 Gb/s mini-SAS connectors (SFF-8644) per I/O module | |
| Management/Status Reporting | CLI via RS232 and 1000Base-T port, SCSI enclosure services (SES) via SAS SFF-8644 ports | |
| Maximum System Configuration | Dual host-connected enclosure with a maximum expanded configuration of 4 enclosures for a total of 336 drives | |
| Device Support | Dual-ported 12 Gb/s SAS | |
| Max Drives per Enclosure | 84 (for a full list of supported drives, please contact your account or sales manager) | |
| Hot-Swappable Components | Drives, power supply units (PSU), cooling modules, side planes, and SBB I/O modules | |
| Physical | Height: 220 mm/8.65 in (5 EIA units) | Width: 483 mm/19 in (IEC rack compliant) | Depth: 933 mm/36.75 in | Weight: 135 kg/298 lb (with drives, no rail kit) | |
| Power Requirements — AC Input | ||
| Input Power Requirements | 180VAC–240VAC, 50Hz/60Hz | |
| Max Power Output per PSU | 2200W | |
| Environmental/Temperature Ranges | ||
| Operating/Nonoperating Altitude | −100 m to 3,000 m (−330 ft to 10,000 ft) / −100 m to 12,192 m (−330 ft to 40,000 ft) | |
| Operating/Nonoperating Temperature | ASHRAE A2, 5°C to 35°C (41°F to 95°F), derate 1°C / 300 m above 900 m, 20°C/hr max rate of change / −40°C to 70°C (−40°F to 158°F) | |
| Operating/Nonoperating Humidity | −12°C DP and 10% RH to 21°C DP and 80% RH, max DP 21°C / 5% to 100% non-condensing | |
| Operating/Nonoperating Shock | 5 Gs, 10 ms, half sine pulses / 20 Gs, 10 ms, half sine pulses | |
| Operating/Nonoperating Vibration | 0.21 Gs rms (5–500Hz) / 1.04 Gs rms (2–200Hz) | |
| Power Supply Units | ||
| Power Supply | Ecodesign (Part UD-PCM2-2200-AC / Model SGT-S-2200ADE00) – Titanium | |
| Power Efficiency 230VAC / 50Hz | Power Factor Conditions (PFC) | |
| 10% Load = >90% | 10% Loading = >0.80 | |
| 20% Load = >94% | 20% Loading = >0.95 | |
| 50% Load = >96% | 50% Loading = >0.95 | |
| 100% Load = >91% | 100% Loading = >0.95 | |
| Power Supply | Ecodesign (Part UD-PSU01-2200-AC / Model FS2K2HS180-xx) – Platinum | |
| Power Efficiency 230VAC / 50Hz | Power Factor Conditions (PFC) | |
| 10% Load = >81% | 10% Loading = >0.80 | |
| 20% Load = >89% | 20% Loading = >0.90 | |
| 50% Load = >93% | 50% Loading = >0.95 | |
| 100% Load = >90% | 100% Loading = >0.95 | |
Full configuration sheet available on request — contact our team.
Backed across India
Every AXL system is supported by a self-reliant supply chain — 100+ channel partners across 40+ service locations — for sourcing, deployment and ongoing maintenance.
Installation, configuration and software-stack setup can be arranged as part of deployment. Talk to our team for SLA and on-site support options.
Enterprise reliability, nationwide support
Engineered for high availability with redundant power and enterprise-grade components — backed by AXL's self-reliant supply chain of 100+ channel partners across 40+ service locations for sourcing, deployment and ongoing maintenance.
