Processor Support |
– 2 x LGA 4710 Sockets
– Intel® Xeon® 6 Processors up to 350 TDP |
Core Logic |
System on Chip (SOC) |
Memory |
– Total Slots: 32x DIMM slots (8 channel per CPU, 16 DIMM per CPU)
– Capacity: Maximum up to 4TB
– Memory Type: DDR5 6400 (1DPC) / 5200 (2DPC) RDIMM
– Memory Size: 128GB, 96GB, 64GB, 32GB RDIMM |
Expansion Slots |
SKU1 (with RAID) up to 11 slots
– 4 x PCIe x16 for dual-slot GPU cards (Gen5 x16, FHFL)
– 1 x PCIe x16 for NIC (BlueField-3, Gen5 x16, FHHL)
– 1 x PCIe x16 for NIC cards (Gen5 x16, FHHL)
– 4 x PCIe x8 for HBA/RAID cards (Gen5 x8, FHHL)SKU2 (without RAID) up to 10 slots
– 4 x PCIe x16 for dual-slot GPU cards (Gen5 x16, FHFL)
– 1 x PCIe x16 for NIC (BlueField-3, Gen5 x16, FHHL)
– 1 x PCIe x16 for NIC cards (Gen5 x16, FHHL) |
Storage Bays |
– 8 x 2.5″ Front Hot-swap Storage Bays
– SKU1 (with RAID): Up to 6 NVMe devices based on HBA/Raid card model
– SKU2 (without RAID): Up to 4 NVMe devices |
Networking |
1 x Management Port (RJ45) |
Graphics |
VGA Aspeed AST2600 64MB |
Front I/O Ports |
– 1 x Mini Display Port
– 2 x USB 5Gbps Ports
– 1 x Debug Port |
Rear I/O Ports |
– 1 x USB 5Gbps Port
– 1 x RJ-45 Management LAN port |
Switch / LED |
Front:
– 1 x Power switch/LED
– 1 x Location switch/LED
– 1 x Message LED
– 1 x Clear CMOS switch
– 1 x Reset switch
– 2 x M.2 LEDs
– 1 x Q-Code/Port 80 LEDRear:
– 1 x Power switch/LED
– 1 x Location switch/LED
– 1 x Message LED |
OS Support |
– Windows Server
– RedHat® Enterprise Linux
– SuSE® Linux Enterprise Server
– CentOS
– Ubuntu
– VMware |
Management Solution |
– Control Center Enterprise (in-band)
– ASMB12-iKVM (for out of band/BMC AST2600) |
Dimension |
800mm x 439.5mm x 175 mm (4U)
31.5″ x 17.3″ x 6.9″ |
Weight |
– Net Weight: 42 Kg
– Gross Weight: 44.23 Kg |
Power Supply |
– 3+1 Redundant 3200W 80 PLUS Titanium power
– 200-240 Vac, 16A (x4) for 6LO |
Environment |
– Operating Temp: 10°C – 35°C
– Non-operating Temp: -40°C – 60°C
– Non-operating Humidity: 20% – 95% (Non-condensing) |
